Product Details
Bag filter system is designed for optimum filtration performance. Its range provides filtration solution for a broad variety of fluid applications in the process industry. They are particularly useful for filtering large volumes of high viscosity liquids. Bag filter is constructed of filter housing, filter bags, internal cage to support bags, positive sealing arrangement, & choice of end connections. The internal support ensures bags will not burst as high differential pressures build up during operation
- High flow rates.
- Low pressure drop.
- High dirt holding capacity.
- Positive sealing arrangement to avoid bypassing.
- Suitable for PP Collar, Rigid Ring & Snap Band Bags.
- Quick opening Tri Clovers & Fly nut design.
- Easy to operate & low maintenance.
- Low down time.
- Flow rate up to 2000 m3/hr & More.
- Customized design available.
- Large-area, heavy-duty baskets.
- Housings are permanently piped.
- Covers are O’-Ring sealed.
Bag filter system suitable for
- Ø 4″ x 10″ Long Filter Bag
- Ø 4″ x 17″ Long Filter Bag
- Ø 7″ x 17″ Long Filter Bag
- Ø 7″ x 32″ Long Filter Bag
Multiple bag filter system suitable for
- 2 Nos. Of Ø 7” x 32” Long Filter Bag
- 3 Nos. Of Ø 7” x 32” Long Filter Bag
- 4 Nos. Of Ø 7” x 32” Long Filter Bag
- 5 Nos. Of Ø 7” x 32” Long Filter Bag
- 6 Nos. Of Ø 7” x 32” Long Filter Bag
- 7 Nos. Of Ø 7” x 32” Long Filter Bag
- 8 Nos. Of Ø 7” x 32” Long Filter Bag
- 9 Nos. Of Ø 7” x 32” Long Filter Bag
Flow Rate
- Capacity: Up to 2000 m3 /hr
Material of construction
- SS 316L
- SS 316
- SS 304
- Super Duplex, Duplex Stainless steel
- CARBON STEEL (ALL GRADE)
- MILD STEEL
- ALLOY METALS
- POLYPROPYLENE
- LEAD LINING on Any Metal
- RUBBER LINING on Any Metal
- PTFE LINING on Any Metal
Bag filter suitable for bag configuration
- PP Collar Bag
- Rubber Collar Bag
- Snap Band Bag
- Rigid Ring Bag
- Flange Collar Bag
Gasket / O Ring Material
- Neoprene
- Nitrile
- Silicone
- Viton
- Buna N
- EPDM
- PTFE
End Connections Available
- NPT / BSP Threaded
- Flanged Table E / Table F
- ANSI B 16.5 Flanged
- DIN Standard
- Tri Clover Adaptors
- SMS /Dairy End Connection
Application - FCIMBG-S1-M-732-2-D
| FCI | Description | Style | Material | Size | Design |
| SBG – Single Bag Filter Housing | S1 – Style -1 | A-SS 304 | 7″ x 32″ x 2 Nos | Duplex | |
| MBG – Multiple Bag Filter Housing | S2 – Style -2 | B-SS 316 | 7″ x 32″ x 3 Nos | Simplex | |
| S3 – Style -3 | C-SS 316 L | 7″ x 32″ x 4 Nos | |||
| D-CARBON STEEL | 7″ x 32″ x 5 Nos | ||||
| E-CSRL | 7″ x 32″ x 6 Nos | ||||
| F-ASTM A 106 | 7″ x 32″ x 7 Nos | ||||
| G-ASTM A 517 | 7″ x 32″ x 8 Nos | ||||
| H-ASTM A 516 |
